PRV Pressure Control Valve
Description
The pressure valve protects the consumer from excessive pressure and is suitable for attachments that have different
maximum pressure requirements. The valve is suitable for double-acting consumers that can be operated with
a flow rate of 60-550 l/min. The proportional pressure for the valve is between 120 - 420 bar. The valve is characterized
by a very flat Volume flow characteristic curve.
This valve version has an SAE 1" 3000 PSI connection, other versions on request.
Characteristics
- SAE 1", 300 PSI port
- Very flat volume flow characteristic
Technical specifications
| Design | Port Size | Operating Pressure | Recommended Flow |
|---|---|---|---|
| PRV | SAE 1", 3000 PSI | 120 - 420 bar | 60 - 550 l/min |
