Main Control Valve MCV-1NB


Modular single or multiple proportional directional valve system for mobile applications. The MCV directional control valve can be used as a main control valve or as an additional section for functional expansion in mobile machines. By connecting to the existing hydraulic system, additional work functions can be easily integrated into the machine. Electric or hydraulic pilot control options can be selected.


  • for single and double acting consumers
  • very flexible due to modular design
  • suitable for load-sensing systems

Technische Daten

DesignPort sizesMaximum pressureMaximum flow
MCV-1NB16G 3/4"420 bar100l/min
MCV-1NB22G 1 "420 bar300l/min
